The MK2 family runs from tactical-grade MEMS to a navigation-grade photonic prototype, in a fraction of the size, weight and power of legacy inertial hardware. Every unit is ITAR-free, made in Canada and individually calibrated. Built to withstand harsh environments, with drivers available to simplify integration.
Tactical MEMS IMU — Value Workhorse
| Optical Gyro Range | N/A |
|---|---|
| Optical Gyro Bias Stability | N/A |
| Optical Gyro ARW | N/A |
| MEMS Gyro Range (X, Y, Z) | ±125 to ±4000 °/s |
| MEMS Gyro Bias Stability (X, Y, Z) | 0.5 to < 1.0 °/hr |
| MEMS Gyro ARW (X, Y, Z) | 0.06 °/√hr |
| Accelerometer Range | ±2, ±4, ±8, ±16 g |
| Accelerometer Bias Stability | < 15 µg |
| Accelerometer VRW | 0.008 m/s/√hr |
| Magnetometer Range | ± 20 G |
Tactical Photonic IMU — Photonic Core
| Optical Gyro Range (Z) | ± 250 °/s |
|---|---|
| Optical Gyro Bias Stability (Z) | 0.5 to < 1.0 °/hr |
| Optical Gyro ARW (Z) | 0.03 °/√hr |
| MEMS Gyro Range (X, Y, Z) | ±125 to ±4000 °/s |
| MEMS Gyro Bias Stability (X, Y, Z) | 0.5 to < 1.0 °/hr |
| MEMS Gyro ARW (X, Y, Z) | 0.06 °/√hr |
| Accelerometer Range | ±2, ±4, ±8, ±16 g |
| Accelerometer Bias Stability | < 15 µg |
| Accelerometer VRW | 0.008 m/s/√hr |
| Magnetometer Range | ± 20 G |
Navigation Photonic IMU — Hybrid PIC
| Optical Gyro Range (Z) | ± 250 °/s |
|---|---|
| Optical Gyro Bias Stability (Z) | 0.005 to < 0.01 °/hr |
| Optical Gyro ARW (Z) | 0.02 °/√hr |
| MEMS Gyro Range (X, Y, Z) | ±125 to ±4000 °/s |
| MEMS Gyro Bias Stability (X, Y, Z) | 0.5 to < 1.0 °/hr |
| MEMS Gyro ARW (X, Y, Z) | 0.06 °/√hr |
| Accelerometer Range | ±2, ±4, ±8, ±16 g |
| Accelerometer Bias Stability | < 15 µg |
| Accelerometer VRW | 0.008 m/s/√hr |
| Magnetometer Range | ± 20 G |
Choose the MK2M2 when size, weight and unit cost drive the design and GNSS is available most of the time. 40 x 40 x 25 mm, 75 g, 1.2 W typ., RS-422 or CAN-FD at up to 500 Hz. In-run bias stability is under 1.0 °/hr typical, 0.5 °/hr minimum, with 0.06 °/√hr angle random walk. In a 21 minute Montreal road test with GNSS position denied, the MK2M2 finished 20.5 m from truth. Drone autopilots, ground robots, rail and mobile mapping payloads.
Choose the MK2E2 when you lose GNSS for minutes at a time and heading is what breaks first. The optical gyroscope is built on a photonic integrated circuit and cuts angle random walk to 0.03 °/√hr against 0.06 on the MK2M2. Same RS-422 or CAN-FD interface, at 78 x 63 x 36 mm, 230 g and 2 W typ. On the same 21 minute GNSS-denied drive it finished 5.7 m from truth against 20.5 m.
The MK2Z is a navigation-grade prototype, not a production part. It puts a navigation-grade optical gyroscope on the Z axis at < 0.01 °/hr in-run bias stability and 0.02 °/√hr angle random walk, for long GNSS-denied runs. 83 x 86.5 x 65 mm, 475 g, 4.5 W typical and 7.5 W maximum. Talk to us about early-access evaluation and what the prototype does and does not yet cover.
